AMD® Athlon XP/Duron (K7) processors
FSB 200-266
Full series of Athlon/Duron CPU including the future Athlon processors.
CHIPSET: SiS® 730S
support AGP 2.0 specification
Integrated 4X AGP in SiS® 730S
Simple LPC I/O - SiS®950/ITE8705
System Hardware Monitor: Integrated in SiS®950/ITE8705
LAN: RealTek 8139C
AC97 Audio Codec
Compliant with AC97 2.1 specification
MEMORY
Two 168-pin DIMM sockets for 3.3V SDRAM (Ready for PC100, PC133)
Maximum: 1.0GB
SYSTEM BIOS
Award 2MB Flash EEPROM
Supports Plug and Play 1.0a, AMP 1.2, Multi Boot, DMI
Full Support for ACPI revision 1.0 specification
I/O INTERFACE
Supports Plug and Play function
PS/2 keyboard and PS/2 mouse connectors
Six USB Ports (Two USB Connectors as header onboard)
One - EPP/ECP mode parallel port
Two - 16550 high-speed serial I/O ports
One VGA Connector
Audio Ports (Line-in, Line-out, Mic-in, CD-in and game port)
Dual PCI IDE interfaces - support four IDE devices (PIO mode 4, DMA Mode 2, Ultra DMA 33/66/100)
Supports 360K~2.88M Byte, 3 Mode FDDs or LS120
ATX Power Supply Connector
ports, Headers and Others:
IrDA header
Extra USB header
Front Panel MIC/Line-out header
LAN header
Green, HDD, Power indicator LED headers
CPU and Case Fan headers
LAN Card Wake Up / Modem Ring Wake Up header
RTC & BATTERY
SiS® 730S included 256 bytes of CMOS SRAM
With CMOS SRAM hardware clear jumper
EXPANSION SLOTS
2 PCI slots, 1 AGP slot, 1 AMR slot, 1 CNR slot
FORM FACTOR
microATX (244mm*220mm)
